What happens when you short out the level shifters on Glasgow with the protection resistors bypassed? I guess we'll find out tomorrow morning. Each of the poor things is dissipating about 1W.pic.twitter.com/QhzCPApYJN
Show this thread
-
Update: no change in current drawn; I stopped the test and nothing seems blatantly broken/shorted. Resuming the test for the rest of the day and after that I'll do a proper analysis. Temp is lower because I took the photo just after restarting the test.pic.twitter.com/gDSWgfbhwI
Show this thread
Conclusion: after 20 hours or so of torture, both pins appear to function normally. Input leakage identical to the rest, output performance at 24MHz identical to the rest (measured with a scope), and they work fine in a basic JTAG test at 3.3V.
-
-
