Electrical Component Cross Sections

31. ožujka 2019.
Take a look at these fascinating and educational cross sections of an LED, resistor, diode, capacitor, and more. (The images in this Moment created by TubeTimeUS are licensed under CC BY-SA 4.0: https://creativecommons.org/licenses/by-sa/4.0/)

here's a cross section of an Ethernet transformer. inside a network adapter, there is one of these in between the Ethernet PHY chip and the cable, providing isolation and safety.

8 replies 33 proslijeđena tweeta 226 korisnika označava da im se sviđa

here's the side view cross section of an Ethernet transformer.

1 reply 7 proslijeđenih tweetova 82 korisnika označavaju da im se sviđa

annotated version of the Ethernet transformer cross section.

1 reply 14 proslijeđenih tweetova 97 korisnika označava da im se sviđa

ok don't try this one at home: this is a cross section of an LR44 alkaline button cell! 🔋⚡️

6 replies 14 proslijeđenih tweetova 149 korisnika označava da im se sviđa

annotated cross section of the LR44 alkaline button cell.

1 reply 15 proslijeđenih tweetova 66 korisnika označava da im se sviđa

inspect this cross section of a BGA-packaged chip.

9 replies 25 proslijeđenih tweetova 194 korisnika označavaju da im se sviđa

annotated cross section of a BGA-packaged chip.

17 proslijeđenih tweetova 97 korisnika označava da im se sviđa

detail showing the vias in the substrate

10 proslijeđenih tweetova 102 korisnika označavaju da im se sviđa

ever wondered what's inside an optocoupler? wonder no more--look Kat this cross section!

10 replies 39 proslijeđenih tweetova 262 korisnika označavaju da im se sviđa

...and here's the annotations for the optocoupler cross section.

9 replies 37 proslijeđenih tweetova 196 korisnika označava da im se sviđa

diodes may look simple, but there's subtlety inside them. check out the cross section of this 1N914.

12 replies 108 proslijeđenih tweetova 472 korisnika označavaju da im se sviđa

here's the annotated cross section of the 1N914 diode. the two Dumet slugs are separate pieces of metal from the leads, and are brazed together during manufacture.

16 proslijeđenih tweetova 121 korisnik označava da mu se sviđa

look at the slug on the left--you may notice it has a taper at the end. i think this end is inserted last, pushing up against the ohmic contact (dot) that's already plated onto the silicon die. then when it is heated to bond the glass to the dumet, it alloys with the contact.

1 reply 1 proslijeđeni tweet 49 korisnika označava da im se sviđa

how does the dot get there? there's a plating bath that applies an AC voltage that's slightly above the diode's voltage rating. only the good diodes get a dot at the cathode end. bad ones break down and plate on both sides. this means they are heavier...

1 reply 4 proslijeđena tweeta 76 korisnika označava da im se sviđa

...to sort out the bad diodes from the good ones, they dump the whole lot into a very dense fluid. the bad diodes sink, and the good ones float, so they just scrape those off and use them. forget what fluid they use, it's apparently quite toxic. barium something-or-other?

6 proslijeđenih tweetova 97 korisnika označava da im se sviđa

the sleeves start out with one slug already installed. these all go into special trays. the diode chips are dumped across the tray which is then vibrated at a very specific frequency, causing the diodes to land dot side up!

2 proslijeđena tweeta 83 korisnika označavaju da im se sviđa

(source: friend of mine who used to be involved with diode manufacturing way back in the day)

1 reply 2 proslijeđena tweeta 76 korisnika označava da im se sviđa

cross section of a headphone plug and jack (aka 1/8" or 3.5mm phone plug). you can see the jack has switches in it. these are often used to disconnect an internal speaker.

16 replies 267 proslijeđenih tweetova 1.113 korisnika označava da im se sviđa

annotated version of the headphone plug and jack cross section.

5 replies 102 proslijeđena tweeta 366 korisnika označava da im se sviđa

this is a small audio transformer, but cut in half and polished.

10 proslijeđenih tweetova 100 korisnika označava da im se sviđa

let's zoom in a bit. now you can see the individual strands of copper!

6 proslijeđenih tweetova 67 korisnika označava da im se sviđa

cross section of a small audio transformer, zoomed in and annotated.

14 proslijeđenih tweetova 75 korisnika označava da im se sviđa

here's a 5mm wide surface mount power inductor that's been sanded down to expose the insides!

27 proslijeđenih tweetova 269 korisnika označava da im se sviđa

and here is the SMD power inductor with annotations. since this is a shielded inductor, it has an outer ferrite shield that helps contain the magnetic field. this reduces the stray magnetic fields which could interfere with other components.

11 proslijeđenih tweetova 88 korisnika označava da im se sviđa

this is a small PCB-mount magnetic speaker that i've cross sectioned.

6 replies 17 proslijeđenih tweetova 187 korisnika označava da im se sviđa

here's the annotated cross section of the PCB-mount magnetic speaker.

5 replies 16 proslijeđenih tweetova 84 korisnika označavaju da im se sviđa

check out this cross section of a bi-color red/green LED! you can see that there are two LED die and two bond wires.

16 replies 50 proslijeđenih tweetova 375 korisnika označava da im se sviđa

this is the annotated version of the red/green bi-color LED cross section.

1 reply 17 proslijeđenih tweetova 110 korisnika označava da im se sviđa

this is a cross section of a 7-segment LED display. you can see the tiny LED chip!

24 proslijeđena tweeta 174 korisnika označavaju da im se sviđa

annotations calling out the various parts of this cross sectioned 7-segment LED display.

23 proslijeđena tweeta 88 korisnika označava da im se sviđa

the LED segment still lights up!

1 reply 6 proslijeđenih tweetova 124 korisnika označavaju da im se sviđa

this is a 3-pin bi-color LED that's been sanded down so you can clearly see the lead frame and LED chips.

14 replies 153 proslijeđena tweeta 869 korisnika označava da im se sviđa

with annotations.

12 proslijeđenih tweetova 91 korisnik označava da mu se sviđa

close-up of the two LED chips. one is shorter than the other.

7 proslijeđenih tweetova 81 korisnik označava da mu se sviđa

cross section of an electret microphone element. 🎤

7 replies 26 proslijeđenih tweetova 212 korisnika označava da im se sviđa

annotated cross section of an electret microphone element. 🎤

13 proslijeđenih tweetova 77 korisnika označava da im se sviđa

you can see the electret film coating on the backplate here. the metallized diaphragm is torn and distorted from the sectioning process

1 reply 1 proslijeđeni tweet 30 korisnika označava da im se sviđa

how it works: the metallized diaphragm and backplate act as the two plates of a parallel plate capacitor. the electret material sits in between, along with a small air gap. the electret gives this capacitor a constant charge, Q...

1 reply 23 korisnika označavaju da im se sviđa

...and since the capacitance changes when the diaphragm deflects due to sound coming in because C = e0*A/d, and because Q = CV, the voltage V = (Q/Ae0) * d. in other words, the voltage is directly proportional to the change in distance between the two plates.

1 reply 1 proslijeđeni tweet 23 korisnika označavaju da im se sviđa

the most fascinating part is the magical electret material. the name is a portmanteau of "electrostatic magnet." it's a material made of polar molecules (positive charge at one end, negative charge at the other) which are all aligned.

1 reply 4 proslijeđena tweeta 51 korisnik označava da mu se sviđa

basically you melt the material while it's in a high voltage electric field, causing all the polar molecules to line up, then you let it cool and solidify. now one side is positively charged while the other side is negatively charged. 🧙‍♀️🧲⚡️

1 reply 2 proslijeđena tweeta 54 korisnika označavaju da im se sviđa

tried a suggestion from and put a little oil on it to clear up the surface a bit. it helped a bit, but now there are tiny bubbles. 😂

6 proslijeđenih tweetova 63 korisnika označavaju da im se sviđa

wow, this bi-color LED is even more beautiful from a slightly different angle!

51 proslijeđeni tweet 310 korisnika označava da im se sviđa
8 replies 51 proslijeđeni tweet 386 korisnika označava da im se sviđa

ever wonder what a 0.1" header and socket look like inside when they're plugged together? wonder no more, rest your eyes on this cross section!

15 replies 66 proslijeđenih tweetova 552 korisnika označavaju da im se sviđa

this is a cross section of a miniature reed relay. they're used by the millions in semiconductor test equipment, then discarded after a million cycles, which happens sooner than you might think!

6 replies 17 proslijeđenih tweetova 158 korisnika označava da im se sviđa

this is the annotated cross section of the miniature reed relay. there's a digital cycle counter in the test equipment these are used in, and when that counter passes 1,000,000, the relays are unplugged and thrown out!

15 proslijeđenih tweetova 73 korisnika označavaju da im se sviđa

here's what the relay looks like, intact, resting comfortably on George. often a semiconductor test board will have one of these relays per pin, and sometimes more.

4 proslijeđena tweeta 49 korisnika označava da im se sviđa

cross section of a PCB-mount slide switch. this one is SPDT. these are quite inexpensive switches!

8 replies 22 proslijeđena tweeta 199 korisnika označava da im se sviđa

here's the annotated cross section of a PCB-mount slide switch. when you push on the actuator, the rocker forces the ball against the spring. the ball rolls over the rocker, applying force to the opposite side, moving the rocker so that it presses up against the opposite contact.

13 proslijeđenih tweetova 91 korisnik označava da mu se sviđa

check out this cross section of a plain old DIP switch. there are 4 switches in this one, and this is one of the switches.

21 proslijeđeni tweet 240 korisnika označava da im se sviđa

here's the annotated version of the DIP switch cross section. it's pretty simple! note that the actuator has two detents simply because it's a symmetrical plastic piece that can be installed in either orientation. only one detent is used.

1 reply 17 proslijeđenih tweetova 95 korisnika označava da im se sviđa

this is a very cheap pushbutton that i've cut in half so you can see how simple it is inside. please ignore the void in the middle of the spring; i use glue to hold the internal parts in place during sectioning.

6 replies 10 proslijeđenih tweetova 128 korisnika označava da im se sviđa

here's the cheap pushbutton switch cross section with annotations.

23 proslijeđena tweeta 85 korisnika označava da im se sviđa

ever wonder what a D-sub connector looks like inside? here's a cross section of a DE-9 plug and receptacle.

21 reply 200 proslijeđenih tweetova 921 korisnik označava da mu se sviđa

naturally i also made an annotated version of this picture so you can tell what's going on. there are a few subtle features of the design, like the tiny little solder dams that prevent solder from wicking up inside the pins and sockets.

39 proslijeđenih tweetova 191 korisnik označava da mu se sviđa

this is a cross section of an electrical component that interacts with you every day! in fact, there's a good chance you've got one very close to you even as you read this. what is it?

14 replies 14 proslijeđenih tweetova 131 korisnik označava da mu se sviđa

it's a vibration motor! this is the annotated cross section. (there's a little air bubble in the upper right that formed in the glue i used to hold it together for the sectioning process.)

1 reply 3 proslijeđena tweeta 62 korisnika označavaju da im se sviđa

cross section of a 2N2222 in a TO-18 metal can

19 replies 108 proslijeđenih tweetova 606 korisnika označava da im se sviđa

here's the annotated version of the 2N2222 in the TO-18 package. the package is actually pretty complicated! lots of materials science here.

6 replies 35 proslijeđenih tweetova 191 korisnik označava da mu se sviđa

from this angle you can see the 2N2222 transistor die. 👾

15 replies 53 proslijeđena tweeta 366 korisnika označava da im se sviđa
Pokreni
Držite pokazivač iznad teksta da biste omogućili korisnika
0:04

the transistor lights up like an LED! it happens if you reverse bias the base-emitter junction and trigger an avalanche breakdown (about 10V). h/t for the technique.

30 proslijeđenih tweetova 175 korisnika označava da im se sviđa

this is a cross section of a quartz crystal in an HC-49 package. ignore the blob of glue on the right, it was to hold the quartz in place during sectioning.

5 replies 16 proslijeđenih tweetova 143 korisnika označavaju da im se sviđa

here's a cross section of a BLOWN LED. why is it so clean? IT CROSS-SECTIONED ITSELF. i have video proof to follow!

11 replies 35 proslijeđenih tweetova 248 korisnika označava da im se sviđa
Pokreni
Držite pokazivač iznad teksta da biste omogućili korisnika
0:04

video of an LED failing and cross-sectioning itself right down the middle! 🤯

15 proslijeđenih tweetova 87 korisnika označava da im se sviđa

annotated version of the LED that failed and cross sectioned itself.

14 proslijeđenih tweetova 85 korisnika označava da im se sviđa

SMA connectors help move RF signals from place to place. here's an SMA mated connector pair cut in half. they are from two different manufacturers, but fit together perfectly -- tight tolerances are critical for good RF performance!

12 replies 114 proslijeđenih tweetova 454 korisnika označavaju da im se sviđa

annotated cross section of a mated SMA connector pair. this annotation barely scratches the surface because there are a lot of very subtle design features that you'd need a whole class to cover.

8 replies 47 proslijeđenih tweetova 162 korisnika označavaju da im se sviđa

this is a type N connector cut in half. the 'N' stands for Neill, since Paul Neill worked on this connector while at Bell Labs. he also worked on the BNC connector (Bayonet Neill-Concelman).

7 replies 65 proslijeđenih tweetova 315 korisnika označava da im se sviđa

this is an annotated cross section of the type N connector. notice the distance between the center conductor and the ground shield changes depending on the dielectric material (air or plastic).

29 proslijeđenih tweetova 125 korisnika označava da im se sviđa

this is a common BNC plug and jack that have been cut in half. it is quite a complicated and subtle assembly!

6 replies 42 proslijeđena tweeta 226 korisnika označava da im se sviđa

here is the annotated BNC plug and jack cross section. notice that the diameter of the center contact is consistent and only changes when it enters the cable, which is when the dielectric diameter changes as well? this is to maintain a constant 50 ohm impedance.

20 proslijeđenih tweetova 105 korisnika označava da im se sviđa

it's fascinating to compare the 75 ohm and 50 ohm BNC connectors! the contacts are the same size to prevent damage when accidentally mating 75 ohm to 50 ohm connectors. to keep the 75 ohm impedance, the connector uses an air gap around the wider contacts.

7 replies 46 proslijeđenih tweetova 187 korisnika označava da im se sviđa

here's a slightly unusual connector. this is an HDBNC (High Density BNC) connector that's been cross sectioned. it's sometimes used for video broadcast equipment (75 ohms) but this example is 50 ohms. the second image compares it with standard BNC.

10 proslijeđenih tweetova 136 korisnika označava da im se sviđa

cross section of the HDBNC connector. there are a bunch of air gaps, dielectric thickness changes, and complex features that are telltale signs of computer modeling and simulation.

6 proslijeđenih tweetova 70 korisnika označava da im se sviđa

this is the cross section of a coaxial cable. it's a LMR-195 cable which is pretty similar to RG-58

7 replies 10 proslijeđenih tweetova 141 korisnik označava da mu se sviđa

annotated cross section of the LMR-195 cable.

8 proslijeđenih tweetova 76 korisnika označava da im se sviđa

cross section of a common USB cable.

19 replies 127 proslijeđenih tweetova 762 korisnika označavaju da im se sviđa

annotated cross section of a typical USB cable.

7 replies 64 proslijeđena tweeta 293 korisnika označavaju da im se sviđa

check out this cross section of an AC power cord. no, the other end is not plugged in.

8 replies 4 proslijeđena tweeta 124 korisnika označavaju da im se sviđa

here's the cross section of the power cable. this is an older cord with outdated color codes. the filler also appears to be a natural material (possibly jute)

8 replies 7 proslijeđenih tweetova 64 korisnika označavaju da im se sviđa

flat phone cable, in cross section.

6 replies 10 proslijeđenih tweetova 157 korisnika označava da im se sviđa

cross section of an old-school VGA cable. i like the color coding. scale is 1mm/div.

6 replies 37 proslijeđenih tweetova 297 korisnika označava da im se sviđa

here's the annotated cross section of the VGA cable. each red, green, and blue signal gets its own little coaxial cable, as does the horizontal sync signal. vertical sync is low frequency and noise tolerant, so it's just a wire. same with the DDC signals (SDA, SCL, +5V, GND)

7 replies 36 proslijeđenih tweetova 166 korisnika označava da im se sviđa

cross section of a DVI-D single link cable. all that aluminum makes me think it's a cheap cable.

11 proslijeđenih tweetova 111 korisnika označava da im se sviđa

and the DVI-D single link cable but with annotations.

9 proslijeđenih tweetova 67 korisnika označava da im se sviđa

closeup of a single differential pair inside the DVI-D single link cable. the geometry has to be tightly controlled to maintain a constant impedance!

7 proslijeđenih tweetova 54 korisnika označavaju da im se sviđa

for your inspection: this cross section of a USB-C connector. it's very complex!

11 replies 151 proslijeđeni tweet 595 korisnika označava da im se sviđa

there really isn't enough room for all the annotations you'd need to fully describe this USB-C connector cross section. so here are the highlights.

41 proslijeđeni tweet 136 korisnika označava da im se sviđa

ever wonder what's inside your USB-C cable? here's a cross section of one! this one can handle 10Gbps.

25 replies 296 proslijeđenih tweetova 985 korisnika označava da im se sviđa

and this is what all the little wires and things are for. SBU stands for "SideBand Use"--DisplayPort alt mode uses them for I2C or CEC commands over a special encoded format. CC is the Configuration Channel and decides VBUS voltage and which end is source/sink.

7 replies 127 proslijeđenih tweetova 399 korisnika označava da im se sviđa

this cat6 cable is shielded and has a drain wire.

7 replies 14 proslijeđenih tweetova 121 korisnik označava da mu se sviđa

and here's a cat6 patch cable! notice the plastic ➕ separator? it reduces crosstalk between pairs.

21 proslijeđeni tweet 157 korisnika označava da im se sviđa

and a super-thin cat5e patch cable.

4 proslijeđena tweeta 45 korisnika označava da im se sviđa

time to cut some network cables in half! here's a cat5e patch cable. 🐈 (thread)

8 replies 23 proslijeđena tweeta 166 korisnika označava da im se sviđa

this is a cross section of a USB-C cable. it's different than the other USB-C cable that i sectioned earlier!

16 replies 77 proslijeđenih tweetova 409 korisnika označava da im se sviđa

annotated USB-C cable cross section. this cable got beat up a bit; one of the micro coax cables has gotten dented or deformed. you can see it's messed with the stranding a bit.

7 replies 51 proslijeđeni tweet 164 korisnika označavaju da im se sviđa

it's Friday, so take a break from work and look at this: a cross section of a Micro-D connector!

36 proslijeđenih tweetova 226 korisnika označava da im se sviđa

annotated version of the Micro-D connector cross section.

15 proslijeđenih tweetova 81 korisnik označava da mu se sviđa
