  1. Disaster? It's certainly stressful when a key "team member" goes down. One of our 40 GHz R&S VNA's woke up sick in the morning. It took 2 days of time and an eBay VME bus extender card to find the fault in a VCO (a cracked capacitor). Fixed (again) 🥳

    Poništi
  2. 27. sij

    A tree antenna? Does it work? You never need to guess an antenna's performance, that's why we test. See measured results for yourself at CONTEST WINNERS

    Prikaži ovu nit
    Poništi
  3. 24. sij

    Win a FREE Tree Antenna. Be a new follower or retweet any of our tweets before Monday morning, and you can win 1 of 3 Tree Antennas. Picked at random! Yes, it's a real antenna with an SMA connector.

    Poništi
  4. Seasons greetings! In the front office we have an LPDA Christmas tree, some whiskey and some whisky. Does anyone else still have a "hospitality tray" for their customers anymore? It may be old fashioned, but it's here to stay.

    Poništi
  5. We've just posted test results and 4-Dimensional gain plots of the LPDA-600-X-POL antenna. It performs well from 650 MHz to 3 GHz and doubles as a Christmas tree. Shown with a bottle of scotch for accurate scaling.

    Poništi
  6. We've just posted test results and 4-Dimensional gain plots of the UWB-2 Vivaldi antenna. It performs well from 500 MHz to 11 GHz.

    Poništi
  7. Here is a 915 MHz bazooka balun (sleeve balun) we created from copper water pipe. This is used for testing tiny 915 MHz PIFA antennas (for small coin cell sized radio sensors) so as to remove the influence of a large attached test coax.

    Poništi
  8. proslijedio/la je Tweet
    13. tra 2019.

    Maarten Braert's amazing FPV patch array using my 4D Antenna Plotting tool developed in partnership with

    Poništi
  9. Waving the flag in the chamber yesterday. It's actually a complex monopole on PCB. Full pattern data with 4-Dimensional gain plots can be found here:

    Poništi
  10. Many thanks to @iHagster for all of his work !

    Prikaži ovu nit
    Poništi
  11. The Raspberry Pi 3 B+ antenna showcases our new 4 Dimensional plotting capability. Here is a animated 3D swept frequency plot using time as the 4th dimension. Video-scrub back and forth to WiFi frequencies of interest. The full write-up is

    Prikaži ovu nit
    Poništi
  12. An eagle flies in the chamber! Actually, we were just testing an eagle themed antenna. Notice where the center of rotation is ... it's at the base of the eagle's tail feathers, the presumed phase center. See the radiation patterns at

    Poništi
  13. Here is a great animation showing a RHCP/LHCP polar pattern of a spiral antenna progressing with frequency over a large 300 to 6000 MHz swept vector gain test. Evaluated in our far field chamber.

    Poništi
  14. We posted another interesting antenna test example. This is a large circularly polarized PCB spiral antenna by the talented @ihagster , and he will be offering them for sale. Our detailed chamber test results are here

    Poništi
  15. Happy Halloween everyone. Pumpkins and an antenna? Why not? Black and orange are signs of Fall and now the cooler weather is in the air. Everybody loves a great antenna this time of year. The LPDA antenna is courtesy of

    Poništi
  16. 3D printing microwave antennas has gone well, and chamber testing proves they perform to spec. Here is a new "smoothing" technique using epoxy. This may be more "environmentally friendly" than solvent smoothing. More results soon

    Poništi
  17. Aren't these capped on the wrong end 😲 While we appreciate the low cost of this 1000 piece batch of eBay SMAs, it does seem misguided to provide protective caps on the solder pins! What do you think?

    Poništi
  18. Proud to be on today. Thanks for spreading the love 💟

    Poništi
  19. This would actually do pretty well above 2 GHz. We've seen worse 😂😂😂

    Poništi
  20. I know a few of you have been waiting for this article. Yes, you can 3D print your own microwave antennas! Assemble Antennas with 3D Printing
